經典款華瑞四合一氣體檢測儀PGM-2400以超高的性價比,簡單實用,以及設置簡便等優點,公司具有良好的市場信譽,專業的銷售和技術服務團隊,憑著經營華瑞氣體檢測儀QRAEII多年經驗,安全使用,無后顧之憂。
華瑞四合一氣體檢測儀可同時顯示4種氣體或1種氣體的數值指標量,當現場某種待檢氣體的指標處于報警范圍時,PGM-2400會自動進行一系列報警動作,閃燈、振動、發聲。QRAEII具備1個LEL傳感器檢測可燃氣、2個EC傳感器檢測有毒氣體、1個SPE傳感器檢測氧氣。QRAEII傳感器名稱(多四個)、實時檢測值,所有檢測的高和低值、TWA/STEL值(氧氣和可燃氣除外)、電池電壓、儀器運行時間,數據采集開/關狀態。
華瑞四合一氣體檢測儀QRAEII是一個可檢測多種有毒有害氣體的便攜式四合一檢測儀,可同時對可燃氣、氧氣和有毒氣體進行檢測。
QRAEII兼容擴散和泵吸兩種工作方式,適合不同應用場所。
華瑞四合一氣體檢測儀體積小巧,操作方便,內置中文菜單,更適合中國用戶使用。
PGM-2400屏幕人性化翻轉顯示設計,方便觀察。
華瑞氣體檢測儀QRAEII可同時安裝幾種傳感器進行檢測:
1)華瑞四合一氣體檢測儀QRAEII催化燃燒傳感器檢測可燃性氣體
2)PGM-2400電化學傳感器檢測硫化氫、一氧化碳等有毒氣體
3)QRAEII固體電解質(SPE)傳感器檢測氧氣,比傳統的電化學傳感器壽命更長、性能更穩定。
The QRAEII is a full-featured, compact, one- to four-sensor gas detector for oxygen, combustibles, hydrogen sulfide, or carbon monoxide. Key features include easy-to-change battery pack, a water-resistant case and a new state-of-the-art O2 sensor.
Key Features
• Patented SPE O2
™ Oxygen sensor features:
– Lead-free design that complies with
RoHS directive
– Extended life resulting in low cost of ownership
– Leak-free design, minimizing downtime
• Best EMI/RFI immunity technology, minimizing
electromagnetic and radio interference
• Easy access to pump, sensors, filter and battery
compartment
• IP-65 water- and dust-resistant case
• Strong, protective, concussion-proof design
• Plug-in sensors: oxygen, combustibles,
hydrogen sulfide, or carbon monoxide
• Intuitive simple-to-operate two-button user
interface
• Multi-language support
• One-button calibration with auto-zero capability
美國華瑞氣體性能參數:
PGM-2400尺寸 |
12.6×7×3.8 cm |
重量 |
擴散式250g,泵吸式350g(含電池) |
抗電磁輻射 |
EMI/RF等級:EMC Directive 89/336/EEC |
|
溫度 |
-20℃~ 50℃ |
|
濕度 |
0% ~ 95%相對濕度(無冷凝) |
|
顯示及操作 |
顯示屏 |
4行圖形液晶顯示器、帶自動背光 |
顯示語言 |
中文/英語+符號 |
|
rae華瑞氣體檢測儀
顯示內容 |
傳感器名稱(多四個)、實時檢測值,所有檢測的高和低值、TWA/STEL值(氧氣和可燃氣除外)、電池電壓、儀器運行時間,數據采集開/關狀態 |
|
按鍵 |
2個操作鍵 |
|
報警參數 |
報警方式 |
95dB@30cm蜂鳴器、LED閃爍、振動 |
報警信號 |
高/低濃度報警、TWA/STEL報警(氧氣和可燃氣除外)、電池電量不足報警、傳感器故障報警、泵阻塞報警(泵吸模式) |
Detector S pecifications
Size Diffusion: 5" L x 2.8" W x 1.5" H (12.5cm x 7.2cm x 3.8cm)
Pump: 5" L x 2.8" W x 2" H (12.5cm x 7.2cm x 5.0cm)
Weight Diffusion: 9 oz (250 g)
Pump: 12 oz (350 g)
Sensors • Catalytic bead for combustibles
• Oxygen: SPE O2™ (non-consumable Solid Polymer Electrolyte technology)
• Toxic: electrochemical for H2S or CO
Battery Interchangeable Lithium-ion or alkaline battery packs
Operating Period Diffusion: Up to 14 hours continuous operation with Lithium-ion battery, up to
10 hours with alkaline battery (typical, without alarm)
Pump: Up to 10 hours with Lithium-ion battery, up to 8 hours with alkaline battery
Display Graphic 4 lines, with LED automatic back light in dim light or alarm condition
Keypad Two-button operation
Direct Readout • Instant reading from up to four sensors
• Oxygen as percentage by volume
• Combustible gas as percentage of lower explosive limit (LEL), scalable
using correction factors
• Toxic gases in parts per million
• High and low values for all gases
• Battery and shutdown voltage
• Date, time, elapsed time, temperature
Alarms • 95dB buzzer (at 30 cm, typical), vibration alarm, and flashing red LED
• High: 3 beeps, vibration and flashes per second
• Low: 2 beeps, vibration and flashes per second
• STEL and TWA: 1 beep, vibration and flash per second
• Alarms: latching with manual override or automatic reset
• Additional diagnostic alarm and display message for low battery
• Pump stall alarm (QRAE II Pump only)
華瑞氣體檢測儀PGM-2400產品結構:
傳感器參數 |
傳感器 |
檢測范圍(%) |
分辨率(%) |
響應時間(T90秒) |
檢測誤差(標定點) |
O2 |
0-30 |
0.1 |
15 |
<±3% |
|
LEL |
0-100 |
1 |
15 |
||
傳感器 |
檢測范圍 |
分辨率 |
響應時間(T90秒) |
檢測誤差(標定點) |
|
CO |
0-1000 |
1 |
25 |
<±3% |
|
H2S |
0-100 |
0.1 |
30 |
||
H2S* |
0-1000 |
1 |
30 |
||
SO2* |
0-20 |
0.1 |
15 |
Gas Monitor Range Resolution
Oxygen 0 to 30.0% 0.1%
Combustible 0 to 100% LEL 1% LEL
Carbon Monoxide 0 to 1000 ppm 1 ppm
Hydrogen Sulfide 0 to 100 ppm 0.1 ppm
